Nestled in the industrial heart of Safat, Sayed Steel has built a strong reputation as a trusted partner for quality materials, and our Alloy Steel T1 Tubing is a prime example of this commitment. We understand the demands of high-performance industries, which is why we ensure our T1 tubing offers a reliable combination of strength and durability for critical applications. When you source from us, you are not just getting a product; you are gaining a supplier dedicated to supporting your projects with material integrity you can count on.
The strength of Alloy Steel T1 comes from its specific composition, which includes chromium and molybdenum, giving it excellent resistance to creep and oxidation even under intense heat. This material maintains remarkable tensile strength and toughness at elevated temperatures that would cause ordinary steels to fail. It’s this ability to perform reliably in demanding thermal environments that makes it such a valuable choice for engineers who need a material that won’t let them down when the heat is on.
Alloy Steel T1 Seamless Tubes Specifications |
||
| Specifications | : | ASTM A/ASME SA213, A691 |
| Dimensions | : | ASTM, ASME and API |
| Tubes Size | : | 1 / 2” OD up to 5” OD, customs diameters also available |
| Outer Diameter | : | 6-2500mm; WT:1-200mm |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / EFW / Fabricated |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
|
Grade |
C≤ |
Mn |
P≤ |
S≤ |
Si≤ |
Mo |
|---|---|---|---|---|---|---|
|
T1 |
0.10~0.20 |
0.30~0.80 |
0.025 |
0.025 |
0.10~0.50 |
0.44~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| T1 | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T1 Tubing in Safat, Kuwait. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T1 Tubing needs!
You will typically find this tubing hard at work in the most challenging sections of power generation plants, such as high-pressure steam lines and superheater tubes, where temperature and pressure are extreme. Its resilience also makes it a go-to material for refineries and petrochemical facilities for process piping and heat exchangers. Essentially, any application that involves moving high-temperature gases or fluids under significant pressure is a perfect fit for the robust capabilities of Alloy Steel T1 tubing.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
