Nestled in the industrial heart of Safat, Sayed Steel has built its reputation on providing top-tier materials to Kuwait’s bustling construction and manufacturing sectors. Their inventory of Carbon Steel A105 Bars exemplifies this commitment, offering a reliable and high-quality solution for critical applications. Known for their strength and durability, these bars are the go-to choice for professionals who demand precision and performance in their projects, ensuring that every specification is met with unwavering consistency.
When it comes to composition, these bars are primarily a combination of carbon, manganese, and silicon, carefully balanced to achieve specific characteristics. This blend results in excellent mechanical properties, including good strength and impressive toughness. They are designed to be highly ductile, meaning they can be shaped and formed for various needs without compromising their structural integrity, making them a versatile material for demanding environments.
| Standard | ASTM A105, ASME SA105 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round bar Size | Diameter: 3-~800mm |
| Hex Bar Size | 2-100mm A/F |
| Square Bar Size | 4 to 100mm |
| Angle Bar Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A105 | 0.35 | 0.10–0.35 | 0.60–1.05 | 0.035 | 0.040 | 0.12 | 0.40 | 0.30 | 0.40 | 0.08 |
| Grade | Yield Strength, Min (MPa ) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A105 | 250 | 485 | 30 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel A105 Bars in Safat, Kuwait. We specialize in premium steel products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability, and performance in critical industrial applications.
| ASTM A105 Round Bar Equivalent | ||
|---|---|---|
| STANDARD | UNS | WERKSTOFF NR. |
| ASTM A105 | K03504 | – |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
| Diameter(Inch) | Carbon Steel A105 Bar Size | Diameter (millimeter) | Carbon Steel A105 Bar Size | Diameter (millimeter) | Carbon Steel A105 Bar Size | Diameter (millimeter2) | Carbon Steel A105 Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | Â | Â |
| 1.375 | #11 | 14 | 14 | 35 | 35 | Â | Â |
| 1.500 | #12 | 16 | 16 | 38 | 38 | Â | Â |
| 1.625 | #13 | 18 | 18 | 41 | 41 | Â | Â |
| 1.750 | #14 | 20 | 20 | 44 | 44 | Â | Â |
| 1.875 | #15 | 22 | 22 | 48 | 48 | Â | Â |
| 2.000 | #16 | 25 | 25 | 51 | 51 | Â | Â |
| 2.250 | #18 | 28 | 28 | 57 | 57 | Â | Â |
| Â | Â | 32 | 32 | Â | Â | Â | Â |
| Â | Â | 36 | 36 | Â | Â | Â | Â |
| Â | Â | 40 | 40 | Â | Â | Â | Â |
| Â | Â | 44 | 44 | Â | Â | Â | Â |
| Â | Â | 50 | 50 | Â | Â | Â | Â |
| Diameter in inch | Size in inch/MM | Weight Lbs/ft & Kg/M |
| 1/16 | 0.0625 1.5875 | 0.010 / 0.01488 |
| 1/8 | 0.125 3.175 | 0.042 / 0.062496 |
| 3/32 | 0.0938 2.38252 | 0.0240 / 0.035712 |
| 5/32 | 0.1563 3.97002 | 0.065 / 0.09672 |
| 7/32 | 0.2188 5.55752 | 0.128 / 0.190464 |
| 3/16 | 0.1875 4.7625 | 0.094 / 0.139872 |
| 1/4 | 0.25 6.35 | 0.167 / 0.248496 |
| 5/16 | 0.3125 7.9375 | 0.260 / 0.38688 |
| 9/32 | 0.2813 7.14502 | 0.211 / 0.313968 |
| 3/8 | 0.375 9.525 | 0.376 / 0.559488 |
| 1/2 | 0.5 12.7 | 0.668 / 0.993984 |
| 7/16 | 0.4375 11.1125 | 0.512 / 0.761856 |
| 9/16 | 0.5625 14.2875 | 0.844 / 1.255872 |
| 11/16 | 0.6875 17.4625 | 1.264 / 1.880832 |
| 5/8 | 0.625 15.875 | 1.043 / 1.551984 |
| 3/4 | 0.75 19.05 | 1.502 / 2.234976 |
| 7/8 | 0.875 22.225 | 2.045 / 3.04296 |
| 13/16 | 0.8125 20.6375 | 1.761 / 2.620368 |
| 15/16 | 0.9375 23.8125 | 2.35 / 3.4968 |
| 1 1/16 | 1.0625 26.9875 | 3.012 / 4.481856 |
| 1 | 1 25.4 | 2.671 / 3.974448 |
| 1 1/8 | 1.125 28.575 | 3.38 / 5.02944 |
| 1 1/4 | 1.25 31.75 | 4.173 / 6.209424 |
| 1 3/16 | 1.1875 30.1625 | 3.77 / 5.60976 |
| 1 5/16 | 1.3125 33.3375 | 4.598 / 6.841824 |
The real strength of A105 bars shines in their wide range of uses, particularly in the construction and energy sectors. You’ll often find them as essential flanges and valve components in piping systems, where their ability to withstand high pressures is crucial. Their reliability makes them a trusted choice for structural supports, machine parts, and other heavy-duty applications, consistently forming the backbone of the infrastructure that powers and supports communities across Kuwait and beyond.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
