We are proud to introduce Sayed Steel, your trusted partner in Safat, Kuwait, for premium industrial materials. As a dedicated manufacturer and supplier, our focus is on delivering reliability and excellence, especially with our range of high-performance pipes. Our Carbon Steel API X65 5L PSL 1 Pipes are engineered to meet the demanding standards of modern energy infrastructure, providing a robust solution for critical projects across the region and beyond. You can count on us for quality that ensures the integrity and longevity of your most important applications.
These pipes are crafted from a specific composition of carbon, manganese, and other trace elements, creating a material known for its remarkable strength and resilience. The “X65” designation signifies a high yield strength, meaning these pipes can withstand immense pressure without deforming. Combined with excellent toughness, this makes them particularly suited for challenging environments where both structural integrity and durability are non-negotiable for safe and efficient operation.
| Standard | ISO 3183 L450/ API 5L X65 |
| Grade of material | X65 / L450 (N, M, Q, R) |
| PSL Level | |
| API 5L X65 PSL1 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X65 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| X65 Carbon Steel SAW | 16″ – 100″ NB |
| API 5L X65 PSL1 ERW and HFW | 1/2” NB – 24” NB |
| Coating for API 5L X65 PSL1 Line Pipe | 3PP, Anti-Rust Oil, CRA clad, FBE, lined pipe, Varnished, Black Painting, 3PE, 3LPE, Galvanized, |
| API 5L Grade X65 Pipe end | Cut Grooves, Square Cut, Grooved, Vibrator Grinding, Plain end (PE), Chamfering, Coupling, Screwed, Pub Joints, Deburring, Thread Cutting, Flanged Ends, Socket, Squared Ends, Threaded Ends (Male & Female), Buttweld, Beveled End (BE) |
| Cutting Facility | Laser Cutting, Sawing, Tapping, Water Jet Cutting |
| Equivalent Standards | JIS, DIN, NFA, BS, CSA, GOST, AWWA, KS, UNI, AISI, IS, EN, API, SAE, ANSI, ISO, ASTM, GB, SS |
| Grade X65 PSL1 Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| API 5L X65 Wall Thickness | SCH-STD, SCH160, SCH80, SCH-XXS, SCH-XS, SCH40 |
| Manufacturing process | Welded, Seamless, Electro Fusion Seam Welded (EFSW), Hot Finish Seamless (HFS), Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), Electric Resistance Welded (ERW), Horizontal Submerged Arc Welded (HSAW), Extrusion, Submerged Arc Welded (SAW) |
| Mass fraction, based upon heat and product analysis a | |||||||
| CS PIPE | |||||||
| C | Mn | P | S | V | Nb | Ti | |
| maxb | max.b | min. | max. | max. | max. | max. | max. |
| 0.28e | 1.40e | – | 0.030 | 0.030 | f | f | f |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 415(60 200) | 520(75 400) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| API 5L X65 Pipe types | API 5L X65 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X65 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X65 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
Sayed Steel is a leading supplier of high-quality Carbon Steel API X65 5L PSL 1 Pipes products in Safat, Kuwait. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
The primary use for these high-strength pipes is in the construction of onshore and offshore oil and gas transmission systems, where they form the backbone of long-distance pipelines. Their robust nature also makes them an excellent choice for high-pressure flow lines within refining facilities, as structural components in large-scale construction, and for other demanding industrial applications that require a conduit capable of handling severe stress and corrosive elements, ensuring dependable performance for years to come.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
