We are pleased to introduce the Carbon Steel EN 10216-4 Pipe from Sayed Steel, your trusted partner in Safat, Kuwait. This product line represents a hallmark of precision and durability, adhering to the exacting standards required for high-pressure applications. As a dedicated manufacturer and supplier, we ensure that every pipe is crafted to offer reliable performance under demanding conditions, providing a robust solution for industries that depend on superior strength and resistance.
The composition of these pipes includes carefully balanced amounts of elements like carbon, manganese, and silicon, contributing to their excellent mechanical properties. They are designed to deliver impressive yield strength, tensile strength, and impact resistance, ensuring they can handle significant pressure and stress. This careful formulation guarantees that the pipes perform reliably in critical environments where safety and durability are non-negotiable.
| Steel Grade | Steel No. | C max. | Si max. | Mn | P max. | S max. | Cr max. | Mo max. | Ni max. | Al max. | Cu max. | N max. | Nb max. | Ti max. | V max. | Nb+Ti+V max. |
| P275NL1 | 1.0488 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,02 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| P275NL2 | 1.1104 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,015 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 650 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10216-4 Pipe products in Safat, Kuwait. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel provides top-grade materials that deliver outstanding performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10216-4 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | Â |
| SCH 5, 10, 40, 80, 160, XXH |
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
You’ll find Carbon Steel EN 10216-4 Pipes hard at work in a variety of demanding settings, making them a go-to choice for numerous industries. They are ideal for constructing high-pressure pipelines in power generation plants, chemical processing facilities, and oil and gas refineries. Their reliability also makes them suitable for structural components in industrial machinery and equipment, where maintaining integrity under continuous stress is absolutely essential.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
