When it comes to robust steel solutions in Safat, Sayed Steel stands out for supplying high-performance carbon steel pipes. Our Carbon Steel EN 10297-1 pipe is a prime example of seamless mechanical tubing designed for demanding environments. Crafted with precision, these pipes are the go-to choice for industries where strength and reliability are non-negotiable, ensuring your projects benefit from materials that meet rigorous international standards.
These pipes are crafted from high-grade carbon steel, containing elements like carbon, manganese, and silicon in precise ratios. This careful composition gives the pipes impressive mechanical properties, including excellent tensile strength and good ductility. They are designed to withstand substantial pressure and stress, making them a dependable choice for heavy-duty applications that require both toughness and resilience.
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | – | – | 20 | ||
| Minimum mechanical properties | ||||||||||||
| Pipe type | Steel grades | Delivery condition | Upper yield limit Re MPa | Tensile strength Rm MPa | Elongation A% | |||||||
| Seamless circular steel tubes for mechanical and general engineering purposes E235, E275, E355, According to PN-EN 10297-1 | For T in mm | For T in mm | 1 | t | ||||||||
| <\= 16 | >16 <\=40 | >40 <\=65 | >65 <\=80 | >80 <\=100 | <\=16 | >16 <\=40 | >40 <\=65 | |||||
| E235 | +A lub+N | 235 | 215 | 205 | 195 | 360 | 360 | 360 | 340 | 340 | 25 | |
| E275 | +A lub+N | 275 | 255 | 245 | 235 | 410 | 410 | 410 | 380 | 380 | 22 | |
| E355 | +A lub+N | 354 | 345 | 315 | 295 | 490 | 490 | 410 | 470 | 470 | 20 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10297-1 Pipe products in Safat, Kuwait. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver superior performance in various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10297-1 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | Â |
| SCH 5, 10, 40, 80, 160, XXH |
Because of their strength, you’ll commonly find EN 10297-1 pipes playing a vital role in critical systems. They are extensively used for hydraulic and pneumatic cylinders, where they form the core pressure-containing component. Beyond that, these pipes are ideal for mechanical and structural applications, from automotive parts and industrial machinery to specialized equipment in construction and engineering projects, where durability and performance are absolutely essential.
