Nestled in the industrial heart of Safat, Sayed Steel stands as your dedicated partner for high-strength steel solutions. We are proud to supply the robust DILLIDUR 400V sheet and plate, a product engineered for those moments when failure is simply not an option. In a city that thrives on durability and progress, we provide the foundational materials that ambitious projects are built upon. When you choose Sayed Steel, you’re selecting a trusted ally committed to fortifying Kuwait’s most critical structures.
The composition of DILLIDUR 400V is a fine-tuned balance, primarily consisting of carbon along with strategic alloying elements that are key to its performance. This specific formulation results in a yield strength of at least 890 MPa, placing it firmly in the high-strength category. It also boasts excellent toughness, even in colder environments, and can be machined and formed with the right techniques. In essence, this material is designed to bear immense loads and resist the challenges of harsh conditions.
Item: Dillidur 400V
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : PVDF, PE, HDP, SMP, EP
| C | Si | Mn | P | S | Mo | Ni | Cr | V | Nb | B |
| ≤ 0.20 | ≤ 0.50 | ≤ 1.80 | ≤ 0.025 | ≤ 0.010 | ≤ 0.50 | ≤ 0.80 | ≤ 1.50 | ≤ 0.08 | ≤ 0.05 | ≤ 0.005 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| DILIDUR 400V | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1000 | 1250 | 10 | 45 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
From the demanding environments of heavy plant and mechanical engineering to the critical supports in structural and plant construction, DILLIDUR 400V is the material of choice. You will often find it forming the backbone of dump truck bodies, robust industrial trailers, and heavy-duty crane components. Its resilience makes it ideal for applications like storage tanks and machinery parts that face constant wear and tear. Essentially, wherever extreme stress and abrasion are part of the daily routine, this material provides a reliable, long-lasting solution.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
