Sayed Steel, a reputable manufacturer and supplier based in Safat, Kuwait, specializes in high-quality SA 516 Grade 65 Sheets and Plates that are engineered for reliable performance in pressure vessel fabrication and high-temperature industrial applications. These plates are celebrated for their exceptional weldability, consistent strength, and impressive toughness, meeting rigorous industry standards and earning preference in challenging environments. Sayed Steel is committed to precision manufacturing, thorough inspections, and timely deliveries, making it a trusted partner for refineries, petrochemical units, boiler manufacturers, and processing industries in need of durable and efficient carbon steel plates for high-pressure operations.
The SA 516 Grade 65 Sheets and Plates are crafted with a balanced mix of carbon, manganese, phosphorus, sulfur, and silicon, ensuring dependable strength and thermal resistance. They boast a robust combination of tensile and yield strength, along with excellent notch toughness, which allows them to perform reliably even under high temperatures and pressure fluctuations. These plates also offer good ductility, making them easy to shape, form, and weld. Their mechanical properties are tailored for pressure vessels, boilers, and components exposed to heat, ensuring consistent structural integrity and long-lasting durability.
Grade :Â ASME SA 516 GR.65 Boiler and Pressure Vessel Steel Plates
Width :Â 1250mm-3000mm
Thickness : 3 – 200 mm/ dimensions up to 4.000 mm
Length :Â 3000mm-11000mm.
Production :Â Hot-Rolled (HR)
Heat Treatment :Â Rolled/Normalised/N+T/QT
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These SA 516 Grade 65 Sheets and Plates find extensive use in applications that demand high-temperature and moderate-to-high pressure resistance. They are the go-to choice for manufacturing boilers, heat exchangers, pressure vessels, storage tanks, and steam-generating units across industries like petrochemical, oil and gas, chemical processing, and power generation. Their robust toughness enables them to endure fluctuating temperatures and high-pressure conditions, making them ideal for refinery equipment and thermal processing units. Additionally, these plates are utilized in industrial reactors, separators, and heavy-duty process equipment where safety, longevity, and reliable performance are crucial.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
